Julius: libjulius/src/wchmm.c File Reference

Go to the source code of this file.


Defines
#define	WCHMM_SIZE_CHECK
	If defined, do wchmm size estimation (for debug only).
#define	COUNT_STEP 500
	Word count step for debug progress output.
Functions
WCHMM_INFO *	wchmm_new ()
	Allocate a new tree lexicon structure.
static void	wchmm_init (WCHMM_INFO *wchmm)
	Initialize content of a lexicon tree.
static void	wchmm_extend (WCHMM_INFO *wchmm)
	Expand state-related area in a tree lexicon by MAXWCNSTEP.
static void	wchmm_extend_startnode (WCHMM_INFO *wchmm)
	Expand word-start nodes area in a tree lexicon by STARTNODE_STEP.
void	wchmm_free (WCHMM_INFO *w)
	Free all data in a tree lexicon.
static int	compare_wseq (WORD_ID widx1, WORD_ID widx2)
	qsort function to sort words by their phoneme sequence.
static void	wchmm_sort_idx_by_wseq (WORD_INFO winfo, WORD_ID windex, WORD_ID bgn, WORD_ID len)
	Sort word IDs in windex[bgn.
static int	compare_category (WORD_ID widx1, WORD_ID widx2)
	qsort function to sort words by their category ID.
static void	wchmm_sort_idx_by_category (WORD_INFO winfo, WORD_ID windex, WORD_ID len)
	Sort word IDs in windex[0.
static int	wchmm_check_match (WORD_INFO *winfo, int i, int j)
	Compare two words from word head per phoneme to see how many phones can be shared among the two.
static void	acc_init (WCHMM_INFO *wchmm, int node)
	Initialize transition information on a node.
static void	add_ac (WCHMM_INFO *wchmm, int node, LOGPROB a, int arc)
	Add an arc to a node.
static void	add_wacc (WCHMM_INFO *wchmm, int node, LOGPROB a, int arc)
	Add a transition arc between two nodes on the tree lexicon.
static void	get_outtrans_list (WCHMM_INFO wchmm, WORD_ID w, int pos, int node, LOGPROB a, int num, int maxnum, boolean insert_sp)
	Make outgoing transition list for given phone position of a word.
static void	wchmm_link_hmm (WCHMM_INFO wchmm, int from_node, int to_node, HTK_HMM_Trans tinfo)
	Add a transition from end node of a phone to start node of another phone.
static void	wchmm_link_subword (WCHMM_INFO *wchmm, int from_word, int from_seq, int to_word, int to_seq)
	Connect two phonemes in tree lexicon.
static void	wchmm_duplicate_state (WCHMM_INFO *wchmm, int node, int word)
	Note:
static int	wchmm_duplicate_leafnode (WCHMM_INFO *wchmm)
	Scan the whole lexicon tree to find already registered homophones, and make word-end nodes of the found homophones isolated from others.
static boolean	wchmm_add_word (WCHMM_INFO *wchmm, int word, int matchlen, int matchword, boolean enable_iwsp)
	Add a new word to the lexicon tree.
static void	wchmm_calc_wordend_arc (WCHMM_INFO *wchmm)
	Scan the lexicon tree to make list of emission probability from the word end state.
boolean	build_wchmm (WCHMM_INFO wchmm, JCONF_LM lmconf)
	Build a tree lexicon from given word dictionary and language model.
boolean	build_wchmm2 (WCHMM_INFO wchmm, JCONF_LM lmconf)
	Build a tree lexicon from given word dictionary and language model.
void	print_wchmm_info (WCHMM_INFO *wchmm)
	Output some specifications of the tree lexicon (size etc.
Variables
static WORD_INFO *	local_winfo
	Temporary work area for sort callbacks.

Detailed Description

Functions to build a tree lexicon (or called word-conjunction HMM here) from word dictionary, HMM and language models are defined here. The constructed tree lexicon will be used for the recognition of the 1st pass. The lexicon is composed per HMM state unit, and various informations about output probabilities, arcs, language model constraints, and others are assembled in the lexicon.

Function Documentation

WCHMM_INFO* wchmm_new ( )

Allocate a new tree lexicon structure.

Returns:: pointer to the newly allocated tree lexicon structure.

Definition at line 70 of file wchmm.c.

Referenced by j_launch_recognition_instance(), and multigram_rebuild_wchmm().

Here is the caller graph for this function:

static void wchmm_init ( WCHMM_INFO * wchmm ) [static]

Initialize content of a lexicon tree.

Parameters:

wchmm

[out] pointer to the lexicon tree structure

Definition at line 103 of file wchmm.c.

static void wchmm_extend ( WCHMM_INFO * wchmm ) [static]

Expand state-related area in a tree lexicon by MAXWCNSTEP.

Parameters:

wchmm

[i/o] tree lexicon

Definition at line 161 of file wchmm.c.

Referenced by wchmm_add_word(), and wchmm_duplicate_state().

static void wchmm_extend_startnode ( WCHMM_INFO * wchmm ) [static]

Expand word-start nodes area in a tree lexicon by STARTNODE_STEP.

(multipath)

Parameters:

wchmm

[i/o] tree lexicon

Definition at line 188 of file wchmm.c.

Referenced by wchmm_add_word(), and wchmm_duplicate_state().

void wchmm_free ( WCHMM_INFO * w )

Free all data in a tree lexicon.

Parameters:

[in] tree lexicon

Definition at line 212 of file wchmm.c.

Referenced by j_recogprocess_free(), and multigram_rebuild_wchmm().

Here is the caller graph for this function:

static int compare_wseq	(	WORD_ID *	widx1,
		WORD_ID *	widx2
	)			`[static]`

qsort function to sort words by their phoneme sequence.

Parameters:

	widx1	[in] pointer to word id #1
	widx2	[in] pointer to wrod id #2

Returns:: 1 if word[widx2] is part of word[widx1], -1 if word[widx1] is part of word[widx2], or 0 if the two words are equal.

Definition at line 299 of file wchmm.c.

Referenced by wchmm_sort_idx_by_wseq().

static void wchmm_sort_idx_by_wseq	(	WORD_INFO *	winfo,
		WORD_ID *	windex,
		WORD_ID	bgn,
		WORD_ID	len
	)			`[static]`

Sort word IDs in windex[bgn.

.bgn+len-1] by their phoneme sequence order.

Parameters:

	winfo	[in] word lexicon
	windex	[i/o] index sequence of word IDs, (will be sorted in this function)
	bgn	[in] start point to sort in windex
	len	[in] length of indexes to be sorted from bgn

Definition at line 348 of file wchmm.c.

static int compare_category	(	WORD_ID *	widx1,
		WORD_ID *	widx2
	)			`[static]`

qsort function to sort words by their category ID.

Parameters:

	widx1	[in] pointer to element #1
	widx2	[in] pointer to element #2

Returns:

Definition at line 373 of file wchmm.c.

Referenced by wchmm_sort_idx_by_category().

static void wchmm_sort_idx_by_category	(	WORD_INFO *	winfo,
		WORD_ID *	windex,
		WORD_ID	len
	)			`[static]`

Sort word IDs in windex[0.

.len-1] by their category ID.

Parameters:

	winfo	[in] tree lexicon
	windex	[i/o] index sequence of word IDs, (will be sorted in this function)
	len	[in] number of elements in windex

Definition at line 398 of file wchmm.c.

static int wchmm_check_match	(	WORD_INFO *	winfo,
		int	i,
		int	j
	)			`[static]`

Compare two words from word head per phoneme to see how many phones can be shared among the two.

Parameters:

	winfo	[in] word dictionary
	i	[in] a word
	j	[in] another word

Returns:: the number of phonemes to be shared from the head of the words.

Definition at line 431 of file wchmm.c.

static void acc_init	(	WCHMM_INFO *	wchmm,
		int	node
	)			`[static]`

Initialize transition information on a node.

Parameters:

	wchmm	[i/o] tree lexicon
	node	[in] node id

Definition at line 458 of file wchmm.c.

Referenced by wchmm_add_word(), and wchmm_duplicate_state().

static void add_ac	(	WCHMM_INFO *	wchmm,
		int	node,
		LOGPROB	a,
		int	arc
	)			`[static]`

Add an arc to a node.

This function is for transition other than self and next node.

Parameters:

	wchmm	[i/o] tree lexicon
	node	[in] node id
	a	[in] transition probability in log10
	arc	[in] transition destination node id

Definition at line 482 of file wchmm.c.

Referenced by add_wacc().

static void add_wacc	(	WCHMM_INFO *	wchmm,
		int	node,
		LOGPROB	a,
		int	arc
	)			`[static]`

Add a transition arc between two nodes on the tree lexicon.

Parameters:

	wchmm	[i/o] tree lexicon
	node	[in] node number of source node
	a	[in] transition probability in log scale
	arc	[in] node number of destination node

Definition at line 519 of file wchmm.c.

Referenced by wchmm_add_word(), wchmm_duplicate_state(), and wchmm_link_hmm().

static void get_outtrans_list	(	WCHMM_INFO *	wchmm,
		WORD_ID	w,
		int	pos,
		int *	node,
		LOGPROB *	a,
		int *	num,
		int	maxnum,
		boolean	insert_sp
	)			`[static]`

Make outgoing transition list for given phone position of a word.

(multipath)

Parameters:

	wchmm	[in] tree lexicon
	w	[in] word ID
	pos	[in] location of target phone to be inspected in the word w
	node	[out] list of wchmm states that possibly has outgoing transition
	a	[out] transition probabilities of the outgoing transitions in node
	num	[out] number of elements in out (found num will be added)
	maxnum	[in] maximum number of elements that can be stored in node
	insert_sp	[in] TRUE if consider short-pause insertion on word end

Definition at line 557 of file wchmm.c.

Referenced by wchmm_add_word().

static void wchmm_link_hmm	(	WCHMM_INFO *	wchmm,
		int	from_node,
		int	to_node,
		HTK_HMM_Trans *	tinfo
	)			`[static]`

Add a transition from end node of a phone to start node of another phone.

Parameters:

	wchmm	[i/o] tree lexicon
	from_node	[in] end node of a phone
	to_node	[in] start node of a phone
	tinfo	[in] transition prob. matrix of the from_node phone.

Definition at line 643 of file wchmm.c.

Referenced by wchmm_link_subword().

static void wchmm_link_subword	(	WCHMM_INFO *	wchmm,
		int	from_word,
		int	from_seq,
		int	to_word,
		int	to_seq
	)			`[static]`

Connect two phonemes in tree lexicon.

Parameters:

	wchmm	[i/o] tree lexicon
	from_word	[in] source word ID
	from_seq	[in] index of source phoneme in from_word from which the other will be connected
	to_word	[in] destination word ID
	to_seq	[in] index of destination phoneme in to_word to which the other will connect

Definition at line 700 of file wchmm.c.

Referenced by wchmm_add_word().

static void wchmm_duplicate_state	(	WCHMM_INFO *	wchmm,
		int	node,
		int	word
	)			`[static]`

Note:

Homophones: As all words need to have an uniq state as a final state in a lexicon tree, homophones should be handled carefully. After primal tree has been made, we look through the tree to find the fully shared or embedded words (homophone or part of other word), and duplicate the last leaf node to have uniq end state.

Isolation of word-end nodes for homophones: duplicate the word-end state, link as the same as original, and make it the new word-end node of the given new word.

Parameters:

	wchmm	[i/o] tree lexicon
	node	[in] the word end node of the already existing homophone
	word	[in] word ID to be added to the tree

Definition at line 755 of file wchmm.c.

Referenced by wchmm_duplicate_leafnode().

static int wchmm_duplicate_leafnode ( WCHMM_INFO * wchmm ) [static]

Scan the whole lexicon tree to find already registered homophones, and make word-end nodes of the found homophones isolated from others.

Parameters:

wchmm

[i/o] tree lexicon

Definition at line 885 of file wchmm.c.

static boolean wchmm_add_word	(	WCHMM_INFO *	wchmm,
		int	word,
		int	matchlen,
		int	matchword,
		boolean	enable_iwsp
	)			`[static]`

Add a new word to the lexicon tree.

The longest matched word in the current lexicon tree and the length of the matched phoneme from the word head should be specified to tell where to insert the new word to the tree.

Parameters:

	wchmm	[i/o] tree lexicon
	word	[in] word id to be added to the lexicon
	matchlen	[in] phoneme match length between word and matchword.
	matchword	[in] the longest matched word with word in the current lexicon tree
	enable_iwsp	[in] should be TRUE when using inter-word short pause option

Definition at line 973 of file wchmm.c.

static void wchmm_calc_wordend_arc ( WCHMM_INFO * wchmm ) [static]

Scan the lexicon tree to make list of emission probability from the word end state.

(non multipath)

Parameters:

wchmm

[i/o] tree lexicon

Definition at line 1420 of file wchmm.c.

boolean build_wchmm	(	WCHMM_INFO *	wchmm,
		JCONF_LM *	lmconf
	)

Build a tree lexicon from given word dictionary and language model.

This function is slow and only used when "-oldtree" option is specified in Julian. Julian without that option and Julius uses build_wchmm2() instead of this.

Parameters:

	wchmm	[i/o] lexicon tree
	lmconf	[in] language model (LM) configuration parameters

Definition at line 1551 of file wchmm.c.

Referenced by j_launch_recognition_instance(), and multigram_rebuild_wchmm().

Here is the caller graph for this function:

boolean build_wchmm2	(	WCHMM_INFO *	wchmm,
		JCONF_LM *	lmconf
	)

Build a tree lexicon from given word dictionary and language model.

This function does the same job as build_wchmm(), but it is much faster because finding of the longest matched word to an adding word is done by first sorting all the words in the dictoinary by their phoneme sequence order. This function will be used instead of build_wchmm() by default.

Parameters:
